Tascam DP-24SD Portable 24 kanaals opname studio met USB & SD

Productbeschrijving

The DP-24SD is a 24-track Digital Portastudio with solid-state recording, a colour LCD and channel strip controls to make recording simple so you stay creative.
Up to eight tracks can be recorded at a time through its combination XLR and 6,3-mm combo jacks. Input processing like compression and limiting are available during recording, as well as guitar amp simulation and multi-effects for use with the instrument-level input.

Once recorded, tracks can be viewed on the large display and mixed with dedicated mixing controls like nineteen linear faders and a dozen channel strip encoders.
Two mixdown effects including reverb and chorus are also available, as well as a mastering effect.
Once finished, songs can be transferred to computer over USB for further processing or sharing with other people.

Features:
– 24-track digital Portastudio
– 12 mono tracks + 6 stereo tracks, 19 faders
– simultaneous playback of 24 tracks
– simultaneous recording of 8 tracks
– 44,1 kHz or 48 kHz sampling rate, 16 bit or 24 bit resolution
– 8 XLR/TRS combo connectors for inputs
– Phantom power supplied on all inputs (switchable A-D, E-H)
– instrument-level input for direct recording of guitar or bass
– inputs A-H and each track equipped with 3-band EQ
– colour LC display and 12-encoder channel strip for simple operation
– dedicated controls for EQ, pan and effect sends
– peak-hold function for level meters on display
– stereo RCA output
– 2 effect send outputs (6,3-mm TS jack)
– headphones output with 70 mW per channel
– remote connector for optional RC-3F footswitch to enable hands-free control of several functions
– automatic punch in/out
– track bounce function
– 8 virtual tracks per track for alternative takes
– up to 99 locate marks per song
– various edit functions (copy insert, copy paste, move insert, move paste, open, cut, silence, clone track, clean out)
– editing on sub-frame level
– undo and redo function with undo history
– dynamics effects for input (limiter, compressor, noise suppressor, exciter)
– guitar multi-effects (noise suppression, amp simulation, compression, chorus, flanger, phaser, tremolo, auto wah, delay)
– mix-down effects (reverb, delay, stereo chorus)
– mastering tools (equalizer, multi-band compressor, normalizer)
– chromatic tuner
– metronome
– file transfer via USB 2.0
– dedicated AC adapter included (GPE248-120200-Z)
– solid-state recording to SD cards for better shock resistance than hard drive recording
– SD card included

Specificaties

– media and file systems recording media SD card (512 MB to 2 GB), SDHC card (4 – 32 GB)
– analogue audio inputs and outputs MIC/LINE INPUTS A to H XLR connector (balanced)
– XLR-3-31 (1: GND, 2: HOT, 3:COLD)
– input impedance 2,4 kOhm
– nominal input level -14 dBu
– maximum input level +2 dBu
– phone connector (balanced) 6,3-mm TRS phone jack
– input impedance >22 kOhm
– input H, when LINE-GUITAR switch is set to GUITAR 1 MOhm
– nominal input level +4 dBu
– maximum input level +20 dBu
– stereo output (L/R) RCA pin jack
– nominal output level -10 dBV
– maximum output level +6 dBV
– output impedance 200 Ohm
– effect sends 1/2 6,3-mm TS phone jack
– nominal output level -10 dBV
– maximum output level +6 dBV
– output impedance 200 Ohm
– monitor output L/R 6,3-mm TRS phone jack
– nominal output level -2 dBu
– maximum output level +14 dBu
– output impedance 200 Ohm
– headphones output 6,3-mm TRS phone jack
– maximum output power 70 mW + 70 mW or more (THD + N 0,1% or less, 32 Ohm load)
– control inputs and outputs USB port USB 4-pin mini-B type
– format mass storage class USB 2.0 High Speed
– remote connector 2,5-mm TRS jack
– frequency response 20 Hz to 20 kHz, +1 dB/-1 dB
– distortion ≤0,01%
– S/N ratio >90 dB
– operating requirements Windows Pentium 300 MHz or faster 128 MB or more memory
– Mac Power PC, iMac, G3, G4 266 MHz or faster 64 MB or more memory
– recommended USB port USB 2.0
– recommended USB host controller Intel chipset
– AC apter (GPE248-120200-Z) 12W (Phantom power on)
– dimensions (W x H x D) 514 x 101 mm x 337mm
– weight 6,2kg
– operating temperature range 5 – 35C
