Mipro MTS-100 16 kanaals digitale vaste tourguide zender met microfoon & lijningang

Productbeschrijving

MTG-100 is an innovative digital wireless tour guide & language interpretation systems.

It is ultra compact, lightweight and easy to use.
Digital design provides crystal-clear audio quality, secured and reliable transmission, and insensitive to interference attributes that are unmatched by the deficiency of simple analog design systems.

It operates in the license-free 865 & 928 MHz ISM band.
ISM band requires no user licensing; thus, no worries about changing groups and channels when operating in multiple countries.
Each band is preset with 16 switchable frequencies and ensures several different tours or groups can be operated at the same venue without interfering with each other.

Lithium rechargeable battery system comprises MTG-100R receiver, MTG-100T transmitter and MTG-100C-4, MTG-100C-12 or MTG-100C-28 storage and charger carry case.
Built-in lithium polymer rechargeable battery is used to resolve the troubles of changing battery and save you a significant amount of money years to come.

This system is ideal for small to large, indoor or outdoor applications for guides, interpreters or presenters to communicate effectively to a group of people, rejecting irritating surrounding noise.

Guided Tours:
Factories, Museums, Tourist Attractions, Zoos & Theme Parks, Cruise Ships & Buses, Schools, Meetings & Lectures, Employee & Dealers Training, Hotels and Resorts, Special Events

Assistive Listening:
Educational Institutions, Corporate Meetings, Training and Seminars, Theaters, Governmental Agencies, Houses of Worship, Conventions and Auditoriums.

Language Interpretation:
Courtrooms, Educational Institutions, Conferences or Conventions, Houses of Worship, Medical Facilities, Employee & Dealers Training, Hotels & Resorts.

Features:
– modularized design for easy set-up, operation and maintenance
– preset with 16 selectable channels
– bright LED channel display
– direct output for low level or switch to wideband amplifier for high level output
– selectable input audio signal level for optimal modulation index
– audio input and RF output LED indicators
– 48V phantom power for condenser microphones

Specificaties

– frequency range CEPT/EU 863-865 MHz / USA 926-928 MHz
– oscillation mode PLL synthesized
– switching bandwidth 2MHz
– preset frequencies 16
– modulation 2 FSK
– stability +/- 0,005%, 0C – +60C
– channel grid 125kHz
– RF output power <10mW (low), <50mW (high)
– antenna 1x TNC 50 Ohm
– spurious <250nW @>1GHz
– transmission range >100m (high setting)
– frequency response 50Hz – 10kHz
– max AF input level <15V RMS (line In)
– microphone input XLR & 6,3mm (combo)
– input sensitivity switch mic or line-level
– input sensitivity adjustment adjustable VR
– phantom power switch ON / OFF
– panel display audio meter, audio limiter, RF hi/low power indicator
– LED channels
– power supply 12-15V DC
– dimensions 210(W) x 44(H) x 206(D)mm
– weight approx. 1,1kg

Notes:
Specifications and appearance are subject to change without notice.
Frequency range and maximum deviation to comply with regulations of different countries.
