LED Dim 3 RGB LED Dimmer DMX OP=OP DE LAATSTE

Productbeschrijving

The LED-Dim 3 is a multi-functional LED dimmer to set the intensity and the color effect for R.G.B. LEDs.

Features:
– R.G.B. Color (Three channel) intensity can be adjusted independently
– Optional drive for X-Chip LED modules
– Output capacity in 3x 2A per channel, total 6A
– DMX address setting by Dip-switch
– DMX Control mode or Manual mode

Specificaties

– Power requirements: 12-24VDC, 6A Max.
– Input: 2 pin terminal socket for (DC power)
– 3 pin terminal socket for (DMX in)
– Output: 3 pin terminal socket for (DMX out)
– 4 pin terminal socket, loading max. 6A
– Housing: Black plastic
– Ingress Protection Rating: IP20
– Control: DMX-512 (1990)
– Connection: Terminal
– Listing: CE certified
– Operation Temperature: 0 deg C to +40 deg C
– Storage Temperature: -20 deg C to +70 deg C
– Dimension (LxWxH): 90 x 40 x 20 mm
– Weight: 150 g
